2 Way-0° 50Ω 50 to 3000 MHz Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
Power Input (as a splitter) 0.5W max Features
• wide frequency band, 50 to 3000 MHz
• low insertion, 1.0 dB typ.
• external resistor required
• aqueous washable
• leads for excellent solderability
• low cost
Applications
• cellular
• PCN
• GPS
