50Ω 10 to 4000 MHz Maximum Ratings
Pin Connections
PRIMARY DOT 3
PRIMARY 1, 2
SECONDARY DOT 6
SECONDARY 4
GND 1, 2
NOT USED 5
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
RF Power 0.4W
DC Current 30mA Features
• PCS
• wideband push-pull amplifi ers
• cellular
• wide bandwidth 10 to 4000 MHz
• balanced transmission line
• excellent return loss
• aqueous washable
