2 Way-90° 50Ω 1325 to 1875 MHz Maximum Ratings Features
• low insertion loss, 0.2 dB typ.
• excellent isolation, 28 dB typ.
• aqueous washable
Applications
• GPS
• balanced amplifiers
• modulators
Pin Connections
SUM PORT 1
PORT 1 (0°) 8
PORT 2 (+90°) 14
GROUND 2,3,4,5,6,9,10,11,12,13
50 OHM TERM EXTERNAL 7
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
Power Input (as a splitter) 1W max
